Appendix C Technical
Specifications
User Manual for EL170/970/470 IP Satellite Modulator/
Demodulator/Modem
version 4.2
193
SHAPING THE FUTURE OF SATELLITE COMMUNICATIONS
L-band monitoring output (default):
Connector SMA (F), 50 ohms;
Return loss > 7 dB;
Level -45 dBm;
Frequency default: identical to L-band output. with options AA-02 /
AA-06: 1080 MHz.
BUC power and reference frequency (optional)
Max. current 1,5 A;
Voltage 24V, 48V;
Frequency 10MHz;
Stability ±5x10-8 over 0°C to 65°C.
With this option installed, the L-band output connectors become N (F), 50 ohms.
10 MHz reference input / output (optional)
Connector BNC (F) 50 ohms;
Input level -3dbm up to 7dBm;
Output level +7dBm.
Demodulator Interface
Dual L-band input (default)
Connector 2 x F-type (F), 75 ohms;
Return loss > 7 dB;
Level -65/-25dBm;
Frequency 950 - 2150 MHz;
Adjacent signal < (Co+7) dBm/Hz where Co = signal level density.
IF-band input (optional, replaces one L-band input)
Connector BNC (F) - 75 ohms;
Return loss > 15 dB;
Level -55 to -15 dBm;
Frequency 50 - 180 MHz;
Adjacent signal < (Co+7) dBm/Hz where Co = signal level density.
LNB power and control
Max. current 350 mA (on selected IFL input);
Voltage:
- 11,5 -14 V (Vertical polarization)
16 -19 V (Horizontal polarization) & additional 22kHz +/- 4KHz (band selection
according to universal LNB for Astra satellites & DiSEqC command
transmission)10 MHz reference.
