Appendix C – Technical
Specifications
User Manual for EL170/970/470 IP Satellite Modulator/
Demodulator/Modem
version 4.2
194
SHAPING THE FUTURE OF SATELLITE COMMUNICATIONS
DVB-S2 performances at PER 1E-S
Short
Frames
Normal Frames
< 15 Mbaud < 45 Mbaud
Config Es/No Es/No
QPSK- 1/3 - -0.6 -0.7
QPSK- 2/5 0.4 0.2
QPSK- 1/2 1 1.4
QPSK- 3/5 3.1 2.8
QPSK- 2/3 3.8 3.6
QPSK- 3/4 4.5 4.3
QPSK- 4/5 5.1 5.1
QPSK- 5/6 5.8 5.5
QPSK- 8/9 6.7 6.6
QPSK- 9/10 - 6.7
8PSK- 3/5 6.5 6.3
8PSK- 2/3 7.4 7.1
8PSK- 3/4 8.6 8.4
8PSK- 5/6 10.2 9.7
8PSK- 8/9 11.4 11.1
8PSK- 9/10 - 11.3
16APSK- 2/3 9.9 9.6
16APSK- 3/4 10.9 10.5
16APSK- 4/5 11.6 11.5
16APSK- 5/6 12.4 12.1
16APSK- 8/9 13.6 13.3
16APSK- 9/10 - 13.6
32APSK-3/4 - 13.6
32APSK-4/5 - 14.5
32APSK-5/6 - 14.9
32APSK-8/9 - 16.1
32APSK-9/10 - 16.5
Table 14 - DVB S2 Performances at PER 1E-S
