NMC-WOLLARD 2021Truax Blvd., Eau Claire, WI 54703, Phone (715) 835-3151, Fax (715) 835-6625
M140 Tow Tractor Manual No. 46054
PAGE 4-3
CHAPTER 4 REPAIR PARTS
MARCH 10, 2014
4 ILLUSTRATED PARTS LIST
Fig.-
Item
NMC
Wollard
Part No.
Vendor
Part No.
Nomenclature E󰀨 Units
Per
Assy
1-
41640 04-40328C Axle - Front, (0AT39), Rear Mount Steering
Cyl
1
46519 Axle - Front, (0AT39), Front Mount Steering
Cyl
47484 Axle - Front, (0AT39), Rear Mount Steering
Cyl
1
41821 03-30468 Front Axle Weldment, Rear Mt Steering Cyl 1
41640-4 Front Axle Weldment, Front Mt Steering Cyl
41640-5 Front Axle Weldment, Rear Mt Steering Cyl
2
41820 03-30469 Knuckle, LH 1
3
41819 03-30470 Knuckle, RH 1
4
41520 03-30265 Tie Rod Tube Assembly (incl. 4A and 4B) 1
4a
NW34967 06-60358 Tie Rod End Assembly, LH (incl. end, boot,
nut, and cotter pin)
Ref
4b
NW34968 06-60360 Tie Rod End Assembly, RH (incl. end, boot,
nut, and cotter pin)
Ref
5
41823 06-61460L Caliper, Disc Brake, R.H. (NOTE: Casting is
stamped L) See Figure 6
1
6
41822 06-61460R Caliper, Disc Brake, L.H. (NOTE: Casting is
stamped R) See Figure 6
1
7
41521 02-20608 Hub Assembly (incl. 7A-7E) 2
7a
41522 06-61425 Hub, Cupped and Studded 2
7b
NW36156 130580500 Inner Cone, #25580 2
7c
NW36160 130581300 Outer Cone, #14125A 2
7d
NW36155 06-60403 Grease Seal 2
7e
NW36164 06-60402 Grease Cup 2
8
NW36842 06-61516 Nut, 9/16-18 Tapered Wheel Ref
9
41828 06-61515 Rotor, 13" Dia. 2
10
NW36162 06-62085 Nut, 1-14 Slotted Hex Jam 2
11
NW36161 06-60295 Washer, Spindle 2
12
41523 06-60779 King Pin 2
43586 King Pin Re pair Kit for Axle 41640 1
13
41524 06-61080 Screw, #10 BHC x .63 lg. 8
14
F9541 06-61081 Washer, #10 Lock 8
15
Comm 390406410 Grease Zerk 4
16
41824 06-60547 King Pin Cap w/ Zerk Hole 4
17
41526 06-61376 Gasket, King Pin Cap 4
18
44153 06-62089 Nut, Jam, 3/8-24 2
19
44152 06-62090 Set Screw, Cup Pt, 3/8-24 x .75 2
20
43096 06-61908 Bearing, Thrust T113 2
21
NW34208 06-60297 Steering Ball 2
22
37813 321900110 Nut, 5/8-18 Slotted Hex 1
23
Comm 324601060 Cotter Pin, 3/32 x 3/4 Lg. 1
24
Comm 320224100 HHCS 1/2-13x2 2
25
F16818 321800090 Nut 1/2-13 Hex 2
