NMC-WOLLARD 140 - Preconfigured Instruments; Stand-Alone and Master Node Configurations

NMC-WOLLARD 2021Truax Blvd., Eau Claire, WI 54703, Phone (715) 835-3151, Fax (715) 835-6625
M140 Tow Tractor Manual No. 46054
PAGE 5-91
CHAPTER 5 MANUFACTURER’S INFORMATION
iv
• Precongured Instruments
Some instruments are precongured at the factory to individual OEM
specications to best meet the needs of the application and end user�
Precongured features include but may not be limited to alarm
conguration, single or dual line display and backlight intensity�
Precongured features are easily modied to satisfy personal preferences�
• Stand-Alone and Master Node Congurations
The instrument is primarily designed to "stand-alone" in applications
where ease of use, limited space and simple installation are critical
criteria in choosing the type of engine/vehicle/vessel monitoring
electronics�
In order to satisfy a wide range of application demands, the hardware
of the 2" CAN Display can be factory congured to drive a maximum
of 16 Beede NexSysLink® Slave Node Instruments (SNI) or Analog
Slave Node Instruments (ASNI)�
The ability to connect with ASNI gauges expands the instruments
capabilities to display analog inputs such as fuel level or air pressure�
When factory congured to drive Beede NexSysLink® SNI or
ASNI gauges, Pin 4 of the 6 pin connector is used for serial data
communication among the instruments�
NexSysLink
®
2" Stand-Alone CAN Display Operation Manual  SAE J1939
CAN DISPLAY MANUAL
OCTOBER 01, 2015
