CHAPTER 5 MANUFACTURER’S INFORMATION
36
NexSysLink
®
2" Stand-Alone CAN Display Operation Manual  SAE J1939
© 2011 Beede Electrical Instrument Co., Inc.
• Parameter Icons & Descriptions
Parameter Icon Description Parameter Icon Description
Throttle Position
Transmission Gear/
Actual Gear/Current
Gear
Total Engine Hours
Transmission Oil
Pressure
Total Vehicle
Distance
Transmission Oil
Temperature
• Menu Navigation Icon Descriptions
Menu Navigation Icon Description Menu Navigation Icon Description
Alarm Indicator
(Blinks)
No CAN Data
Present
Selection Arrow
Cursor
Higher Than Alarm
Threshold Indicator
Blinking Bar Cursor
(Shown under
number 0, zero)
Lower Than Alarm
Threshold Indicator
