NMC-WOLLARD 140 - Figure 1-23: Popup Fault, Warning & Alarm Screens; Popups Notification Screens

NMC-WOLLARD 2021Truax Blvd., Eau Claire, WI 54703, Phone (715) 835-3151, Fax (715) 835-6625
M140 Tow Tractor Manual No. 46054
PAGE 5-116
CHAPTER 5 MANUFACTURER’S INFORMATION
24
NexSysLink
®
2" Stand-Alone CAN Display Operation Manual  SAE J1939
© 2011 Beede Electrical Instrument Co., Inc.
• Popups Notification Screens
Turning on popups provide a highly visible alert screen when a system Fault, Warning or Alarm occurs�
Figure 1-23: Popup Fault, Warning & Alarm Screens
ALARM
WARNING
FAULT
Alarm Notication Screen
Warning Notication Screen
Fault Notication Screen
Pressing the Enter switch clears the
notication screens.
Pressing the Up or Down switch
displays the Fault, Warning or Alarm
condition detail information screen.
Fault, Warning and Alarm popup screens remain displayed until acknowledged by pressing the Enter
switch� Pressing the Enter switch returns the last displayed CAN parameter prior to the occurrence of
the Fault, Warning or Alarm condition�
For Faults and Warnings, the Fault LED and Warning LED remain illuminated after pressing the Enter
switch to acknowledge and clear the notication screen�
After pressing the Enter switch for Alarms, a blinking "bell" icon appears in the upper left corner of the
CAN parameter display screen to indicate an alarm condition exists�
Pressing the Up or Down switch when a notication screen appears brings up the Fault, Warning or
Alarm detail information display�
Note: If the condition that caused the Fault, Warning or Alarm clears, the notication screens and bell
icon disappears and the alert LEDs turn o�
CAN DISPLAY MANUAL
OCTOBER 01, 2015
