M140 Tow Tractor Manual No. 46054
PAGE 4-17
CHAPTER 4 REPAIR PARTS
4 ILLUSTRATED PARTS LIST
JANUARY 31, 2009
Fig.-
Item
NMC
Wollard
Part No.
Vendor
Part No.
Nomenclature E󰀨 Units
Per
Assy
7-
Brakes - Rear, Dual Wheels Ref
0
39557K Kit, Brake, LH, TA268 (Inc.
4,8-12,13,16-20)
Ref
39556K Kit, Brake, RH, TA268 (Inc.
4,8-12,14,16-20)
1
NW33918 A-3736-M-2353 Plate Assy - Back ing 1
3
39283 15-X-1801 Screw and Washer Assy 2
4
37856 2297V4520 Rod (3E157) 3
5
39286 15-X-1799 Screw and Washer Assy (3E157) 2
6
NW34154 A-3261-K-349 Cyl in der Assy-Wheel (3E157) 1
7
39287 A-3211-M-4433 Spi der Assy - Brake (3E157) 1
8
39288 1259-L-298 Pin, Brake An chor (3E157) 2
9
38757 2558-M-767 Spring Re turn - Black, LH (3E157) 1
38764 2558-N-768 Spring Re turn - Green, RH (3E157)
10
38758 2257-B-132 Clip-Hold Down, Shoe 6
11
NW33929 A8-3722-Y-1715 Shoe Brake and Lin ing Assy 2
12
38759 2758-P-770 Spring Re turn - Gray 1
13
39552 2297-Y-4523 Nut-Ad justing Bolt, LH 1
38760 2297-Z-4524 Nut-Ad justing Bolt, RH
14
39553 2297-W-4521 Bolt-Ad justing, LH 1
38761 2297-X-4522 Bolt-Ad justing, RH
15
38762 2245-U-99 Sleeve, Ad justing Bolt (3E157) 1
16
39555 3501-Y-1013 Le ver, LH (3E157) 1
38763 3501-Z-1014 Le ver, RH (3E157)
17
38078 1245-V-437 Link (3E157) 1
18
38079 A1-2247-G-111 Le ver Assy - Auto Ad just(3E157) 1
19
37249 1245-V-438 Link (3E157) 1
20
38764 2558-N-768 Spring - Re turn, Green, LH (3E157) 1
38757 2558-M-767 Spring - Re turn, Black, RH (3E157)
21
39289 1245-W-439 Push Rod (3E157) 2
22
39290 2260-J-36 Boot (3E157) 2
23
39291 2230-V-204 Pis ton (3E157) 2
24
39292 3261-K-349 Housing - Wheel Cyl in der (3E157) 1
25
39293 A-2258-Q-771 Spring Assy - Re turn(3E157) 1
26
39294 1205-H-1984 Cup, Brake Cyl in der (3E157) 2
32
39295 1250P536 Plug, Brake Rear Ac cess 2
33
39296 1250Q537 Plug, Brake Rear Ac cess 2
34
39297 1250R538 Plug, Brake Rear Ac cess 1
35
44745 MPS 2867 LH Kit, Brk Adj, LH (In cludes items
13,14,15)
1
36
44746 MPS 2868 RH Kit, Brk Adj, RH (In cludes items
13,14,15)
1
NS
NW36697 FC-5354 Kit, Wheel Cyl in der Re pair (63477) Ref
