NMC-WOLLARD 140 - Page 257

NMC-WOLLARD 2021Truax Blvd., Eau Claire, WI 54703, Phone (715) 835-3151, Fax (715) 835-6625
M140 Tow Tractor Manual No. 46054
PAGE 4-57
CHAPTER 4 REPAIR PARTS
Fig.-
Item
NMC
Wollard
Part No.
Vendor
Part No.
Nomenclature E󰀨 Units
Per
Assy
23-
42552 Seat Assembly with Slide Ref
NW26697E Seat, Op tional Passenger Ref
43966 Pas sen ger Seat, Op tional Ref
43965 Seat, Driver’s w/ Armrest Ref
1
NW23843 Seat Assy, w/Slide (0X098) 2
NW23734 Cush ion, Seat 1
NW23733 Cush ion, Back 1
38138 Arm rest (Op tional) 1
38969 Hip Guard (Op tional) 1
2
F09549 Flat Washer, 5/16 8
3
F09546 Lock Washer, 5/16 8
4
F09547 Hex Nut, 5/16-18 8
5
NW34728 7066 Seat Belt (0X0P8) 1
6
90559 Slider Set, W/ Han dle 1
NS
38478 Bracket, Seat, RH 1
NS
38138 Arm Rest (Optional) 1
NS
42343 Plate, Seat 1
4 ILLUSTRATED PARTS LIST
JANUARY 31, 2008
