M140 Tow Tractor Manual No. 46054
PAGE 5-40
CHAPTER 5 MANUFACTURER’S INFORMATION
C-6 TRANSMISSION SERVICE
The drive plate (ywheel) will not support a load. None of the weight of the transmission
must be allowed to rest on the drive plate during removal or installation.
The transmission and torque converter must be removed and installed
as an assembly to prevent damage to the front bushing or front oil seal.
1. Remove the engine/transmission assembly.
2. Shift transmission into NEUTRAL. Place drain pan under transmission uid pan.
Starting at rear of pan and working toward front, loosen attaching bolts and allow
uid to drain. Finally remove all of pan attaching bolts except two at front to allow
uid to further drain. With uid drained, install two bolts on rear side of pan to
temporarily hold it in place.
3. Remove converter drain plug access cover from lower end of converter housing.
Matchmark torque converter with drive plate (for easier installation).
Do not attempt to rotate the drive plate or torque converter by prying or
using force or you will damage the drive plate.
4. Remove converter-to-ywheel attaching nuts. Place a wrench on crankshaft pulley
attaching bolt to turn converter to gain access to bump switch.
5. With wrench on crankshaft pulley attaching bolt, turn converter to gain access to
converter drain plug. Place a drain pan under converter to catch uid and remove
plug. After uid has been drained, re-install plug.
6. Remove capscrew and self-locking nut securing transmission shift cable to shift lever
on transmission.
7. Remove all hardware securing transmission shift cable to transmission and free the
cable.
8. Disconnect hydraulic lines at transmission.
9. Disconnect park brake cable. Disconnect driveshaft and slide shaft rear ward from
transmission. Install a seal installation tool in extension housing to prevent uid
leakage.
JANUARY 31, 2008
