NMC-WOLLARD 2021Truax Blvd., Eau Claire, WI 54703, Phone (715) 835-3151, Fax (715) 835-6625
M140 Tow Tractor Manual No. 46054
PAGE 5-56
CHAPTER 5 MANUFACTURER’S INFORMATION
C-6 TRANSMISSION PARTS
Fig.-
Item
NMC
Wollard
Part No.
Vendor
Part No.
Nomenclature Eff Units
Per
Assy
1 302351 87650-S2 Plug, Dry Seal Tapered Thread,1/8-27 1
2 302352 D2AZ-7017-A Shaft, Input 1
3 Comm 58619-S2 HHCS, 5/16-18 x 1.25 7
4 Comm 20346-S8 HHCS, 5/16-18 x 0.75 5
5 302353 C9AZ-7A108-A Support Assy, Front Pump 1
6 302354 C6AZ-7B258-A Bushing, Front Oil Pump 1
7 302355 C8AZ-7A103-B Pump Assembly, Front Oil 1
8 302356 C2AZ-7A248-A Seal Assy, Front Oil Pump, Small 1
9 38792 E4TP-EZ Torque Converter Assembly Ref
10 302357
C6AZ-7D014-A
C6AZ-7D014-B
C6AZ-7D014-C
C6AZ-7D014-D
C6AZ-7D014-E
Washer, Front Pump Support Thrust
#1, 0.057” thick
#2, 5/64” thick
#3, 3/32” thick
#4, 0.114 thick
#5, 0.119 thick
1
1
1
1
1
11 300134 C6AZ-7A248-B Seal Assy, Front Oil Pump, Large 1
12 302358 C6AZ-7A136-A Gasket, Front Oil Pump to Case 1
13 302359 D9AZ-7D034-B Band Assy, Intermediate Servo 1
14 302360 C8AZ-7A548-C Seal, Direct Clutch Piston Oil 1
15 302361 C8AZ-7C099-A Seal, Clutch Piston Oil 1
16 302362 C9AZ-7D044-A Drum Assembly, Intermediate Brake
(includes item #15)
1
17 302363 C6AZ-7D430-C
Strut, Intermediate Band Anchor
1
18 302364 C6AZ-7D029-C Strut, Intermediate Brake Band 1
19 302319 C6AZ-7D025-A
Seal, Intermediate Band Servo Piston
Cover
2
20 302365 C9AZ-7A262-B
Piston Assy, Direct Clutch
1
21 302366 C7ZZ-7B488-A Spring, Direct Clutch Piston Spring 10
22 302367 C6AZ-7A527-A Retainer, Direct Clutch Piston Spring 1
23 302368 377136-S Ring, Retaining 1
24A 302369 D6AZ-7B164-B Plate, Direct Clutch, Internal A/R
24B 302370 C6AZ-7B442-A Plate, Direct Clutch, External A/R
25 302371 C6AZ-7B066-B Plate, Clutch Pressure 1
26 302372 C6AZ-7C096-A Washer, Thrust 1
27 NSS Ring, Retaining (see item #39) 1
28 302373 E0AZ-7D019-A Seal, Forward Clutch Cylinder 2
JANUARY 31, 2008
