NMC-WOLLARD 140 - Page 466

NMC-WOLLARD 2021Truax Blvd., Eau Claire, WI 54703, Phone (715) 835-3151, Fax (715) 835-6625
M140 Tow Tractor Manual No. 46054
PAGE 5-58
CHAPTER 5 MANUFACTURER’S INFORMATION
C-6 TRANSMISSION PARTS
Fig.-
Item
NMC
Wollard
Part No.
Vendor
Part No.
Nomenclature Eff Units
Per
Assy
49 302394
C6AZ-7D235-
Race, Sun Gear Thrust Bearing
(Rear)
1
50
302395 C6AZ-7D064- Shell, Input 1
51
302396 C6AZ-7D066- Washer, Input Sheel Thrust, 3-3/4 x
3/64
1
52
302397 377155-S Ring, Retaining, 5-7/32” 1
54
302398 C6AZ-7D006- Planet Assembly, Reverse 1
56
302399 C6AZ-7A153- Gear Ring (74 teeth) 1
57
302400 C9AZ-7D164- Hub, Output Shaft 1
58
302388 377132-S Ring, Retaining, 4-21/32” 1
59
302401 C9AZ-7D422- Thrust Washer, Output Shaft Hub 1
60
302402 387031-S5 Ring, Retaining, Copper, 5/64” thick
1
61
302403 377300-S Ring, Retaining, 2” 2
62
NOT USED
63
302404 C6AZ-7D234-A Bearing Assembly, Sun Gear Thrust 1
64
302405 C6AZ-7B067-B Hub, Clutch, Reverse, 5-1/2” 1
65
NOT USED
66
302406 385044-S Ring, Retaining, 7-1/8” 1
67A
302407 D6AZ-7B164-A Plate, Reverse Clutch, Internal
(friction)
A/R
67B
302408 C6AZ-7B442-B Plate, Reverse Clutch, External
(steel)
A/R
68
302409 D8AZ-7E085-A
Spring, Clutch Pressure, Reverse,
6-7/8”
1
69
302410 C8AZ-7D403-A Seal, Outer, Reverse Clutch Piston 1
70
302411 C7AZ-7D404-A Seal, Inner, Reverse Clutch Piston 1
71
302412 D6AZ-7D406-A Retainer and Spring, Reverse Clutch 1
72
302413 D8AZ-7D402-A Piston Assembly, Reverse Clutch
(Includes item #68)
1
73
302414 C6AZ-7D167-A
HHCS, Overrunning Clutch Case,
5/16-24 x 2.00
5
74
302415 C9AZ-7D171 Race, Inner, Overrunning Clutch 1
76
302416 D0AZ-7A089-A Clutch Assembly, Overrunning 1
77
302417 D6TZ-7060-A Shaft, Output 1
JANUARY 31, 2008
