NMC-WOLLARD 2021Truax Blvd., Eau Claire, WI 54703, Phone (715) 835-3151, Fax (715) 835-6625
M140 Tow Tractor Manual No. 46054
PAGE 1-31
CHAPTER 2 MAINTENANCE
1 SERVICING
AUGUST 31, 2008
Approved Fluid Types:
III (down to -10º F)
Allison Type C-3 10W (down to 10º F)
*Allison Type C-3 30 (down to 32º F)
*Use 30 when ambient temperatures are consistently above 86º F.
Cold Check Procedure
1. Park the tractor on a level surface and apply parking brake.
clear the hydraulic circuits of air. Shift to neutral and allow the engine to idle
between 1000-1500 rpms.
NOTICE!
dipstick to insure that no dirt or debris enters the system.
3. After wiping the dipstick clean, check the oil level. If the oil on the dipstick is
within the COLD RUN band, it is safe to operate the transmission until the
oil is hot enough to perform a HOT CHECK.
5. Perform a HOT CHECK as soon as possible.
oil filler
drain plug
FIGURE 10. PLUG AND FILLER TUBE LOCATIONS
