Nokia Beacon G6 - Configuring Port Forwarding; Table 7-28 Port Forwarding Parameters; Figure 7-41 Port Forwarding Page

Configure a Beacon G6
Application configuration
Configuring port forwarding
Beacon G6
7.40 Configuring port forwarding
1
Click Application→ Port forwarding in the left pane. The Port forwarding page displays.
Figure 7-41 Port forwarding page
2
Configure the following parameters:
Table 7-28 Port forwarding parameters
Field
Description
Application Name
Select an application name from the list.
The default is Custom Settings.
WAN port
Enter the WAN port range.
LAN port
Enter the LAN port range.
Internal client
Select a connected device from the list and enter the associated IP address.
The default is Custom Settings.
June 2022
Issue 1
Use subject to agreed restrictions on disclosure and use.
3FE-49949-AAAA-TCZZA 131
