Nokia Beacon G6 - Figure 6-2 Beacon G6 Reset Button at the Bottom of the Device

156 pages

To Next Page

To Previous Page

Install or replace a Beacon G6

Install a Beacon G6

Beacon G6

Figure 6-1 Beacon G6 connections

WPS

WLAN

LAN1

LAN2

LAN3

WAN

ON/OFF

POWER

37374

Figure 6-2 Beacon G6 reset button at the bottom of the device

Reset Button

37379

Connect the Ethernet cables to the RJ-45 ports; see Figure 6-1, “Beacon G6 connections”

(p. 55)for the location of the RJ-45 ports.

June 2022

Issue 1

Use subject to agreed restrictions on disclosure and use.

3FE-49949-AAAA-TCZZA 55

Wi-Fisecurity/

on/offbuttons

1GbpsLAN

2.5GbpsLAN

2.5GbpsWAN

On/off

button Power
