Beacon G6 unit data sheet
Beacon G6 general description
Figure 5-1 Beacon G6
WP S
WL AN
INT ERN ET
WAN
PO WER
37373
This device provides the following functions:
• Dual-band concurrent 4x4 802.11b/g/n/ac/ax 2.4 GHz and 4x4 802.11ac/ax MU-MIMO 5 GHz
• Supports 802.11b/g/n/ac/ax 4x4 Wireless 2.4 GHz MIMO; Channel bandwidth 20, 40 MHz, auto
• Supports 802.11ac/ax 4x4 Wireless 5 GHz Mu-MIMO; Channel bandwidth 20, 40, 80, 160 MHz,
auto
• One 2.5G/1G/100M/10M -Base-T standard RJ-45 WAN port
• One 2.5G/1G/100M/10M -Base-T standard RJ-45 LAN port
• Two 1G/100M/10M -Base-T standard RJ-45 LAN ports
• All RJ-45 ports support auto-negotiation and MDI/MDIX
• 512 MB NAND Flash with bad block management, 1 GB DDR3 RAM
• WLAN on/off push button
• WPS on/off push button
• Reset button
• Video and high speed Internet access
• Built-in layer 2 switch; Line Rate L2 traffic
• IP video distribution
• 4 inner antennas for 2.4G, 4 inner antennas for 5G
• WPA2, WPA-PSK/TKP
• WPA2, WPA2-PSK/AES
Use subject to agreed restrictions on disclosure and use.
40 3FE-49949-AAAA-TCZZA
