Nokia Beacon G6 - Table 7-20 US Classifier - Classifier Parameters; Figure 7-27 US Classifier - Classifier Page

Configure a Beacon G6
Network configuration
Configuring Upstream (US) Classifier
Beacon G6
Figure 7-27 US Classifier - Classifier page
5
Configure the following parameters:
Table 7-20 US Classifier - Classifier parameters
Field
Description
Interface
Select an interface from the list; for example, None, LAN, 2.4G SSID, or 5G SSID.
The option None indicates that all interfaces are selected.
Source MAC
Select the toggle button to enter a source MAC address.
Source IP
Select the toggle button to enter a source IP address.
Source Port
Select the toggle button to enter a source port.
