Nokia N96 Service Manual

Voltage limits
Parameter Description Value
VMSTR Master reset threshold (N2200) 2.2V (typ.)
VMSTR+ Threshold for charging, rising (N2300) 2.1V (typ.)
VMSTR- Threshold for charging, falling (N2300) 1.9V (typ.)
VCOFF+ Hardware cutoff (rising) 2.9V (typ.)
VCOFF- Hardware cutoff (falling) 2.6V (typ.)
SWCOFF SW cutoff limit
~3.25V (defined
by SW)
The master reset threshold controls the internal reset of EM ASICs. If battery voltage is above VMSTR, N2300
charging control logic is alive. Also, RTC is active and supplied from the main battery. Above VMSTR, N2300
allows the system to be powered on although this may not succeed due to voltage drops during start up. SW
can also consider battery voltage too low for operation and power down the system.
Power key
The system boots up, when power key is pressed (adequate battery voltage, VBAT, present).
Power down can be initiated by pressing the power key again (the system is powered down with the aid of
SW). Power key is connected to EM ASIC N2200 via PWRONX signal.
RM-247
System Module
Issue 1 COMPANY CONFIDENTIAL Page 7 –7
Copyright © 2008 Nokia. All rights reserved.

Nokia N96 Specifications

General

Panel type	TFT
Display diagonal	2.8 \
Display resolution	240 x 320 pixels
Display number of colors	16.78 million colors
Internal memory	16 MB
Front camera type	Single camera
Rear camera resolution	2592 x 1944 pixels
USB 2.0 ports quantity	1
Multimedia Messaging Service (MMS)	Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network
Audio formats supported	AAC, eAAC+, MP3, WMA
Image formats supported	EXIF
Ringer type	Polyphonic
Form factor	Slider
Product color	Gray
Talk time (2G)	150 h
Battery capacity	950 mAh
Standby time (2G)	200 h
Continuous audio playback time	14 h
Continuous video playback time	5 h
2G standards	HSCSD
Data network	wcdma
Bluetooth version	2.0+EDR

Weight and Dimensions

Depth	20 mm
Width	55 mm
Height	103 mm
Weight	125 g
