Nokia N96 - Flash Concept with FPS-10, SS-62 and

Flash concept with FPS-10, SS-62 and SB-7
Figure 8 Flash concept with FPS-10, SB-7 and JBT-9
Type Description
Product specific tools
FS-51 Flash adapter
Other tools
CU-4 Control unit
FPS-10 Flash prommer box
PKD-1/PK-1 SW security device
SB-7 WLAN test box
SS-62 Flash adapter base
SX-4 Smart card
PC with Phoenix service software
Cables
XCS-4 Modular cable
PCS-1 Power cable
USB cable
RM-247
Service Tools and Service Concepts
