Nokia N96 Service Manual

Camera interfaces
Camera system
Camera sensors are connected directly to Nomadik 1.5, which has embedded image pre-processing block.
Electrical interface consists of Nomadik 1.5 IPI2C for controlling camera module, a CCP2 interface for camera
data (Main camera using CCP0. secondary camera CCP1), camera clock (ExtClk) and CAM0_SD / CAM1_SD data
(Main camera / secondary camera) signal made by GPIO-pin for controlling camera shutdown. Camera is
powered by Touareg1bis VIO SMPS (1.8V) and discrete linear regulator (2.8V). Main camera is 5MP Stingray;
secondary camera is Acme lite (VGA). Camera system includes led flash with flash driver and indicator led.
Flash driver and indicator led get control data through I2C from Nomadik. Two GPIO-pins are needed for
enabling flash driver and flash timing strobe.
RM-247
System Module
Issue 1 COMPANY CONFIDENTIAL Page 7 –21
Copyright © 2008 Nokia. All rights reserved.

Nokia N96 Specifications

General

Panel type	TFT
Display diagonal	2.8 \
Display resolution	240 x 320 pixels
Display number of colors	16.78 million colors
Internal memory	16 MB
Front camera type	Single camera
Rear camera resolution	2592 x 1944 pixels
USB 2.0 ports quantity	1
Multimedia Messaging Service (MMS)	Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network
Audio formats supported	AAC, eAAC+, MP3, WMA
Image formats supported	EXIF
Ringer type	Polyphonic
Form factor	Slider
Product color	Gray
Talk time (2G)	150 h
Battery capacity	950 mAh
Standby time (2G)	200 h
Continuous audio playback time	14 h
Continuous video playback time	5 h
2G standards	HSCSD
Data network	wcdma
Bluetooth version	2.0+EDR

Weight and Dimensions

Depth	20 mm
Width	55 mm
Height	103 mm
Weight	125 g
