Flash concept with SS-62 and CA-89DS
Figure 6 Flash concept with SS-62 and CA-89DS
Type Description
Product specific tools
FS-51 Flash adapter
Other tools
CU-4 Control unit
FLS-5 Flash device
SS-62 Flash adapter base
PC with Phoenix service software
Cables
CA-89DS Cable
PCS-1 Power cable
USB cable
RM-247
Service Tools and Service Concepts
Issue 1 COMPANY CONFIDENTIAL Page 2 –23
