CA-101 Micro USB cable
The CA-101 is a USB-to-microUSB data cable that allows connections
between the PC and the phone.
CA-112DS Easy flash II cable
The CA-112DS easy flash II cable is used for connecting phone DC port
to the PROMMER facilities (FLS-5, FPS-20).
CA-128RS RF tuning cable
Product-specific adapter cable for RF tuning.
•
Table 8 Attenuation values
Band Attenuation Rx/Tx
GSM850/900 0.2...0.3 dB
GSM1800/1900 0.3...0.4 dB
WCDMA850 0.2...0.3 dB
WCDMA2100 0.4...0.6 dB
RM-247
Service Tools and Service Concepts
Issue 1 COMPANY CONFIDENTIAL Page 2 –15
Copyright © 2008 Nokia. All rights reserved.
