Type Description
GPIB control cable
Module jig service concept with JBT-9 and smart card reader
Figure 10 Service concept with JBT-9 and smart card reader
Type Description
Product specific tools
MJ-131 Module jig
Other tools
CU-4 Control unit
JBT-9 Bluetooth test and interface box
PKD-1/PK-1 SW security device
SX-4 Smart card
Measurement equipment
PC with Phoenix service software
Smart card reader
Cables
DAU-9S MBUS cable
PCS-1 DC power cable
XRS-6 RF cable
GPIB control cable
RM-247
Service Tools and Service Concepts
Issue 1 COMPANY CONFIDENTIAL Page 2 –27
Copyright © 2008 Nokia. All rights reserved.
