Nordson ColorMax Customer Product Manual

Operation
4-9
Part 1108061-02
E 2015 Nordson Corporation
Typical Operating Settings
The settings listed here are approximate. You may need to adjust these
settings to obtain the desired results.
Operating Air Pressures
NOTE: Refer to the Spectrum Feed Center manual for operational settings
and air pressures.
Table 4-10 Typical Operating Air Pressures
Air Pressure Setting
Input (System) 7 bar (100 psi)
Cartridge Filter Pulse
(After Filter)
4 bar (60 psi)
Waste Hopper Fluidizing
(After Filter)
1 bar (15 psi)
Conveyor Air Knife 4 bar (60 psi)
Floor Blow-off 5.5 bar (80 psi)
Gun Blow-off
AfterFilter Pulse Timer Board Settings
Table 4-11 Typical Pulse Valve Timer Board Settings
Timer Setting
On Time (Duration) 0.07 seconds
Off Time (Delay) 90 seconds
Typical Blow-off Settings
Table 4-12 Typical Blow-off Settings
Timer Setting
Floor Blow-off Delay 5 seconds
Floor Blow-off Pulse Duration 0.25 seconds
Gun Blow-off ON Duration 25
