Nordson ColorMax Customer Product Manual

Parts
8-10
Part 1108061-02
E 2015 Nordson Corporation
Fittings and Connectors
Part Description Note
972119 Elbow, male, 1/4 in tube x 1/8 in. NPT
972126 Elbow, male, 6 mm tube x 1/8 in.
972276 Elbow, male, 8 mm tube x 1/8 in.
972716 Connector, male, 1/4 in. tube x 1/8 in. NPT
972157 Connector, female, 6 mm tube x 1/8 in. NPT
972142 Elbow, male, 6 mm tube x 1/4 in.
972141 Connector, male, 6 mm tube x 1/8 in.
971100 Connector, male, 6 mm tube x 1/4 in.
183804 Plug, 6 mm tubing
972183 Elbow, male, 3/8 in. tube x 1/4 in NPT
972125 Elbow, male, 10 mm tube x 1/4 in.
972282 Connector, male, 8 mm tube x 1/4 in.
972283 Connector, ml, round, 10 mm tube x 1/4 in. A
1051108 Connector, male, 16 mm tube x 1/2 in.
148256 Plug, 10 mm tubing
972240 Elbow, male, 12 mm tube x 1/2 in.
972143 Elbow, male, 16 mm tube x 1/2 in.
139040 10 tube connector, 1/4 in. tubing, male
139041 10 tube connector, 1/4 in. tubing, female
249446 Plug, male, 10 tube connector, 6 mm B
249469 Plug, male, 10 tube connector, 1/4 in. B
249447 Socket, female, 10 tube connector, 6 mm B
249461 Socket, female, 10 tube connector, 8 mm B
249470 Socket, female, 10 tube connector, 1/4 in. B
327748 Connector w/check valve, male, 8 mm tube x 1/4 in. C
NOTE A: For through-hole applications, as in sheet metal panel, where hex version connector may not
work.
B: New style SMC ten-tube connector fittings.
C: Used in Sure Coat manual control unit for flow and atomizing air.
