Nordson ColorMax Customer Product Manual

Parts
8-1
Part 1108061-02
E 2015 Nordson Corporation
Section 8
Parts
To order parts, call the Nordson Finishing Customer Support Center at
(800) 433-9319 or your local Nordson representative.
Afterfilters, Fan Motors, and Fans
See Figure 8-1.
Item Part Description Quantity Note
− 1106103
AFTERFILTER, 9000, 380/415V, 60Hz
1
1 1106106
S MOTOR, 40HP, 380/415V, 60Hz, 326T
1
2 1106105
S KIT, fan wheel, housing, 9000, 60Hz
1
− 1106102
AFTERFILTER, 9000, 200V, 60Hz
1
1 1106113
S MOTOR, 40HP, 200V, 60Hz, 326T
1
2 1106105
S KIT, fan wheel, housing, 9000, 60Hz
1
− 1106101
AFTERFILTER, 9000, 200V, 50Hz
1
1 1106114
S MOTOR, 40HP, 200V, 50Hz, 324T
1
2 1106065
S KIT, fan wheel, housing, 9000, 50Hz
1
− 1106100
AFTERFILTER, 11250, 380/415V, 60Hz
1
1 1106109
S MOTOR, 50HP, 380/415V, 60Hz, 326T
1
2 1106104
S KIT, fan wheel, housing, 11250, 60Hz
1
− 1105795
AFTERFILTER, 11250, 380/415V, 50Hz
1
1 1105834
S MOTOR, 50HP, 380/415V, 50Hz
1
2 1105546
S KIT, fan wheel, housing, 11250, 50Hz
1
− 1106068
AFTERFILTER, 11250, 200V, 50Hz
1
1 1106108
S MOTOR, 50HP, 200V, 50Hz, 326T
1
2 1105546
S KIT, fan wheel, housing, 11250, 50Hz
1
− 1106069
AFTERFILTER, 11250, 200V, 60Hz
1
1 1106107
S MOTOR, 50HP, 200V, 60Hz, 364T
1
2 1106104
S KIT, fan wheel, housing, 11250, 60Hz
1
− 1106067
AFTERFILTER, 15750, 380/415V, 60Hz
1
1 1106112
S MOTOR, 75HP, 380/415V, 60Hz, 405T
1
2 1105802
S KIT, fan wheel, housing, 15750, 60Hz
1
− 1105805
AFTERFILTER, 15750, 200V, 60Hz
1
1 1106111
S MOTOR, 75HP, 200V, 60Hz, 405T
1
2 1105802
S KIT, fan wheel, housing, 15750, 60Hz
1
− 1105804
AFTERFILTER, 15750, 200V, 50Hz
1
1 1106110
S MOTOR, 75HP, 200V, 50Hz, 405T
1
2 1105800
S KIT, fan wheel, housing, 15750, 50Hz
1
