Parts
8-2
Part 1108061-02
E 2015 Nordson Corporation
Afterfilter Parts
See Figure 8-1. This parts list applies to 9000, 11250, and 15750 CFM
systems. 22,000 CFM systems use a Torit afterfilter; refer to the Torit
manual for service parts.
Item Part Description Quantity Note
3 777773
VALVE, pulse, 25 mm
AR
4 779301
KNOB, star, M10
38 A
5 1105384
BRACKET, final filter hold down
AR A
6 156995
Filter, final, 20 x 24 in., internal
AR A
7 778535
KIT, C clamp, side
2
8 778534
KIT, C clamp, end
2
9 779366
FLUID PLATE, 7500, 9000, 11250 afterfilter
1
10 779237
GASKET, U, rubber, fluid plate
4 m
11 778739
NUT, M16, hex, Nylok
AR B
12 778604
WASHER, flat, GB/T 95, 16 mm
AR B
13 778549
SUPPORT, hanger top, filter
AR B
14 778548
PIN, 5 x 100
AR B
15 778547
SUPPORT BAR, filter
AR B
16 778550
SUPPORT, hanger bottom, filter
AR B
17 156996
FILTER, 36 in., PowderGrid, center mount
AR B
18 777737
TIMER, 15 step, 220 VAC
1 C
18 1105830
TIMER, 21 step, 220 VAC
1 D
19 780324
TRANSFER PUMP
2 E
20 780267
DRUM, 50 lb, 2 inlets, w/hose
1 F
21 779052
PAD, leveling, afterfilter base
4
NS 778267
GAUGE, Magnahelic, 0−5 kPa, 18”
1
NOTE A: 9000 and 11250 CFM afterfilters use 7 final filters, 15750 CFM afterfilter uses 10 final filters. Two
brackets and four knobs are used for each final filter.
B: 9000 and 11250 CFM afterfilters use 15 cartridge filters; 15750 CFM afterfilter uses 21 cartridge filters.
Each filter requires one each of items 11−16 for mounting.
C: Used on 9000 and 11250 CFM afterfilter.
D: Used on 15750 CFM afterfilter.
E: Refer to Transfer Pump parts list for repair parts.
F: Waste container, must be vented to afterfilter and grounded.
AR: As Required
NS: Not Shown
