PAGE 50 1010/2020 INSTALLATION AND PROGRAMMING MANUAL
COPYRIGHT © 2000, NOTIFIER INERTIA PTY LTD
Example: Programming Monitor Modules
Monitor Module 15 on Loop 3 is an MMX-2 and is to be programmed to monitor a full zone of
conventional smoke detectors, activate software zone (Z13), and is also mapped to Annunciator
address "02" point "03".
ENTER LXX(D/M)YY, ZXXX OR AXXPYY FOR PT INSTALL
(BCKSPC TO ABORT)
L3M15
ENTER TYPE ID SCON
ENTER CONTROL-BY-EVENT (Z13)
ENTER 20 CHARACTER CUSTOM LABEL BASEMENT DETECTORS
IS THE TRACKING OPTION TO BE DE-ISOLATED FOR THIS
DEVICE? (Y=YES, N=NO).
N
DO YOU WANT THIS POINT MAPPED TO AN ANNUNCIATOR?
(Y=YES,N=NO)
Y
ENTER AXXPYY FOR ANNUNCIATOR POINT MAPPING A2P3
Example: Programming Control Modules
Control Module 19 on Loop 2 is to be programmed to be a relay output and turn on in response to
an alarm condition on either of two software zones (Z13 or Z29), and also mapped to Annunciator
address "02" point "04". Also as this output is a bell we want to set the bell isolate and walk test
flags.
ENTER LXX(D/M)YY, ZXXX OR AXXPYY FOR PT INSTALL
(BCKSPC TO ABORT)
L2M19
ENTER TYPE ID FORC
ENTER.CONTROL-BY-EVENT OR(Z13 Z29)
ENTER 20 CHARACTER CUSTOM LABEL MAIN LOBBY BELL
IS THE BELL ISOLATE OPTION TO BE ENABLED FOR THIS
DEVICE? (Y=YES,N=NO)
Y
IS THE WALK TEST OPTION TO BE ENABLED FOR THIS
DEVICE? (Y=YES,N=NO)
Y
DO YOU WANT THIS POINT MAPPED TO AN ANNUNCIATOR?
(Y=YES,N=NO)
Y
ENTER AXXPYY FOR ANNUNCIATOR POINT MAPPING A2P4
