NCS Mounting and Connections Installation
NCS Manual PN 51095:B1 3/08/02 11
Figure 1.5 Installation of MON-19BLK
DB-15 Cable
MON-19BLK
NCS Computer
Monitor
Connection
Ground - Green
Neutral - White
Power Cord
Fuse
B
lack
W
hite
G
reen
HSP-121B
Junction Box
AC - Black
NCSmoninstonyxnrtnet.cdr
