NCS Integrated Operation The History Manager
NCS Manual PN 51095:B1 3/08/02 57
.
Figure 4.11 Archive History Dialog Box
Automatic History Backup
The NCS can be automatically setup to back up a history file when the NCS reaches a user
selectable number of entries, with ranges from 10,000 to 100,000 events. In addition, the history
database can be backed up any day of the month, ranging from 1 to 28.
The current history file will be saved to a file name made up of the current date with a “a” prefix,
denoting an automatic backup. If more the one backup has occurred in any given day, a “01” will
be added to the file. For example, “a061298-1-.his” indicates the first file backed up automatically
on June 12th, 1998. A “a061298-2.his” file indicates that a second file was backed up that day.
The path and filename of the old history file will be saved in the new history file. All history files
are backed up in the \{install}\HistoryArchives directory.
4.1.1.1 Upload/Download (UPDL)
The upload / download window is used to upload or download the database from a node. Options
are available to initiate uploads, downloads, schedule uploads, and abort any current actions.
Information about the node number, status indication and progress indication will be displayed by
the upload / download. Select UPDL under the View menu option and a Main Screen will appear
showing nodes and their completion percentage, refer toFigure 4.12.
Figure 4.12 Upload/Download Main Window
hisback.tif
