Menu Options for Programming Programming
NCS Manual PN 51095:B1 3/08/02 27
Acknowledge
Initiating a acknowledge command will transmit a point acknowledge or block acknowledge
message to all appropriate nodes. The nodes transmitted to are limited by the nodes programmed
into the system and the user password level.
If the highest priority event in the system is a fire alarm condition, a point acknowledge message
will transmit to the node, acknowledging the point. If the highest priority event in the system is a
security alarm or lower event, a block acknowledge command will be transmitted in the same
manner as in the Command area.
Any point acknowledge or block acknowledge initiation commands will be logged in the history
manager and current event window, if successfully completed. If this message could not be
completed, a error message will be displayed to the user.
System Reset
Initiating a system reset command transmits a system reset message to all appropriate nodes. The
nodes transmitted to are limited by the nodes programmed into the system, the user password level,
and the nodes selected by the user.
The system reset initiated command is logged into the history manager and current event window,
if successfully completed. If this message was not completed, a error message will be displayed to
the user.
Signal Silence
Initiating a signal silence command transmits a signal silence message to all appropriate nodes.
The nodes transmitted to are limited by the nodes programmed into the system, the user password
level, and the nodes selected by the user.
2.5.1.14 Current Operator Field
The current operator field is a window that shows the name of the current operator of the NCS.
Pressing the (...) button to the right will display information about the current operator. Refer to
Figure 2.15.
Figure 2.15 Current Operator Field
2.6 Menu Options for Programming
2.6.1 Administration Menu
The Administration menu (refer toFigure 2.16) gives the user access to three commands: System
Setup, Network Operations, and the Archive History Database.
Figure 2.16 The Administration Menu
2.6.1.1 System Setup
When clicking on System Setup under the Administration Menu, the user will gain access to the
System Administration dialog box. In this dialog box there are five tabs: General NCS, User
Account, Printer, Voice, and Graphic Configuration, all in which contain NCS programming
options.
ncsoper.tif
ncsadmin.tif
