Product Introduction
1040-0011 Revision 12
Optically isolated, 5- to 24V-compatible, 5mA min, 15mA max
NOTE: Current limiting not provided.
Laser control
(continued)
RS-232. Provided for configuration
and status access to appropriately
equipped lasers
4, programmable polarity and level or edge sensitivity
A marking job may contain an
instruction that pauses execution until
one of these signals is asserted by
external equipment.
Optically isolated, 5 to 24V source or sink, 1mA min, 5mA max,
4.7K ohm current limiting provided
A marking job instruction may specify
the state of any of these signals.
Open-collector, reverse bias protected, 1K ohm pull-up to 5V, 24V
capable, 500mA sink.
4, dedicated function outputs
Asserted when a BeginJob instruction
is executed, and de-asserted when an
EndJob instruction is executed
Asserted when marking is in progress
Asserted if an error is detected; un-
asserted means system ready.
