Asserted if a job is active but not
necessarily marking yet, e.g. waiting
on a trigger input
Open-collector, reverse bias protected, 1K ohm pull-up to 5V, 24V
capable, 500mA sink.
Automation
interfaces
(continued)
3, optically isolated inputs
A marking job may contain an
instruction that pauses execution until
this signal is asserted by external
equipment. Note that this function
can also be achieved using the
AUX_GPI[4..1] and START signals.
Causes the card to execute a soft reset
forcing a complete re-initialization of
the firmware
Causes the job execution control logic
to abort the current job and return to
an idle state; useful upon detection of
an interlock break
Optically isolated, 5 - 24V source or sink, 1mA min, 5mA max, 4.7K
ohm current limiting provided
A marking job may contain an
instruction that pauses execution until
this signal is asserted by external
equipment. Note that this function
can also be achieved using the
AUX_START and AUX_GPI[4..1] signals.
Optically isolated, 5V sink only
2 channels, digital quadrature input (A & B phases per channel)
