Product Introduction
1040-0011 Revision 14
AUX_AMOTF [1..0]_DP
AUX_BMOTF [1..0]_DN
Used for tracking objects in motion
and automatically compensating for
that motion while marking. Also
known as marking-on-the-fl.
Compensation can be software
configured to be applied to either the
X- or Y-axis
RS-422 differential, 110-ohm termination, optional 887-ohm
pullup/down resistors on the negative differential input to
support TTL encoders
2 inputs. Laser interlock signals are passed through the laser
interface connector and made accessible on the main board
through a separate connector. The connector is optionally
configurable to provide a default interlock assertion as required
by an attached laser. NOTE: Signals are not actively monitored.
100/1000 BaseT-compatible
1 RS-232, RTS/CTS interface capable, reserved for future smart
touch-panel user interface access
1 RS-232, RTS/CTS interface capable, for general use (included in
the AUX connector)
1 RS-232, Rx/Tx only, for serial communication to a laser (included
in the laser connector)
1 RS-485, Rx/Tx only, for smart-stepper controller access (included
in the AUX connector)
1 USB 2.0 host port for access to external Flash memory disks or
other peripherals
1 USB 2.0 header for remote location of USB connector
+15 - 48 volts, 6W. Attached USB devices may add an additional
5W consumption.
Optional 24V for optical isolation circuits
