Connector J13 (Auxiliary) Signal Descriptions
Odd-numbered Pins (1 – 63)
Even-numbered Pins (2 – 64)
AUX_BUSY
Asserted when a BeginJob
instruction is executed; de-
asserted when an EndJob
instruction is executed.
13
14
AUX_LASING
Asserted when marking is in
progress. It is de-asserted when an
EndJob instruction is executed.
AUX_GPO1
A marking job WriteDigital
instruction may specify the state of
this signal.
15
16
AUX_GPO2
A marking job WriteDigital
instruction may specify the state of
this signal.
AUX_GPO3
A marking job WriteDigital
instruction may specify the state of
this signal.
17
18
AUX_GPO4
A marking job WriteDigital
instruction may specify the state of
this signal.
EXT-VCC5V0
Fused 5 Volts available for logic on
an Auxiliary I/O board
19
20
GND
Digital ground reference
AUX_AMOTF0_DP
Primary mark-on-the-fly encoder
input. Expected to be connected
to an RS-485 positive “A” phase
differential signal or a 5V TTL
signal.
21
22
AUX_AMOTF0_DN
Primary mark-on-the-fly encoder
input. Expected to be connected to
an RS-485 negative “A” phase
differential signal.
AUX_BMOTF0_DP
Primary mark-on-the-fly encoder
input. Expected to be connected
to an RS-485 positive “B” phase
differential signal or a 5V TTL
signal.
23
24
AUX_BMOTF0_DN
Primary mark-on-the-fly encoder
input. Expected to be connected to
an RS-485 negative “B” phase
differential signal.
AUX_SCL
Reserved for future use
25
26
AUX_SDA
Reserved for future use
