15.2.4. Terminal Trouble

Communication is disabled.

Figure 15-10 : Terminal trouble

Communication is disabled.

(Improper characters are displayed.)

Check CN1 connector wiring.

Check Driver Unit control power.

Baud rate setting of Driver Unit and terminal are different.

(Shipping set of the baud rate for the Driver Unit and the

Handy Terminal FHT11 is 9600 b.p.s.)

Check frame ground.
