1.3.1 Motherboard connectors
The connectors not mentioned in the table below are not used.
Connector Function Connector Function
CN1 COM5 for Touch screen CP Compact flash connector
CN3 Dual Channel LCD interface FAN CPU1 CPU fan power supply
CN6 Inverter PWR1 Power connector
CN9 I/O board connection PWR2 Power connector
CN10 HDD LED JP2 VGA cable
CN12 Badge reader IDE1 IDE for CD-ROM on I/O board
CN19 Front board connector IDE2 HDD
CN24 Power LED DIMM1/DIMM2 RAM slot
CN30 Loudspeakers MINI PCI Expansion connector
CN31 Audio cable
