1.8 BADGE READER (FIELD OPTION)
The 3-track badge reader is integrated in the operator display and can read magnetic stripe cards. The data
acquired are managed by the application program according to the related functions.
The Explor@ system supports PS/2 and RD-232 type badge readers. Both types have the same hardware.
Figure 1-18
1.8.1 Badge reader board
Figure 1-19
1.8.2 Badge reader board connectors
Connector Function Connector Function
CN1 Motherboard connection CN2 Badge reader connection
BADGE
READER
CN1 CN2
