Olivetti Explor 200XS - Front Panel I;O Board; Front Panel I;O Board Connectors

1-12 XZAC4074
1.4 FRONT PANEL I/O BOARD
Figure 1-12
1.4.1 Front panel I/O board connectors
Connector Function Connector Function
CN 1 Not used PWR1 Not used
CN 2 Motherboard connection USB 1 USB 3
SW 1 ON/OFF button USB 2 USB 4
CN2 CN1
SW1
PWR1
USB1
USB2
