Olivetti Explor 200XS - Jumpers Rear Panel I;O Board

1-14 XZAC4074
1.5.2 Jumpers rear panel I/O board
To access jumpers JP1 and JP2 of the rear I/O board, operating from under the module, loosen the screw and
remove the cover as shown in the figure. The default settings of the jumpers are indicated in the table beside
the cover.
Figure 1-14
Figure 1-15
2
1 2
2 3
3
2
1
JP1 JP2
LOOSEN
DEFAULT
SETTINGS
