1-10 XZAC4074
1.3.2 Motherboard jumpers
1.3.2.1 Jumper JP1 – Compact Flash Master/Slave Setting
Function JP1 (pins closed)
Master
◎1-2
Slave N/C
◎ Default setting
1.3.2.2 Jumper JP5 – CMOS Operating Mode Setting
Function JP5 (pins closed)
CMOS Normal
◎N/C
CMOS Reset 1-2
◎ Default setting
1.3.2.3 Jumper JP9 – Power Mode Setting
Function JP9 (pins closed)
ATX Power
◎N/C
AT Power 1-2
◎ Default setting
1.3.2.4 Jumper JP10 – CPU Frequency Setting
Function JP10 (pins closed)
◎ FSB 400
1-2,3-4
FSB 533 3-4
◎ Default setting
1.3.2.5 Jumpers JP7 – JP8 – CPU Voltage Setting
CPU
JP7 (pins closed) JP8 (pins closed)
3-4,1-2 (NC)
9-10,5-6 (NC)
7-8 (NC)
Mobile Celeron 1.2 G (1.3V)
NC
11-12 (NC)
3-4,1-2
9-10,5-6
7-8
◎ P4, Celeron
11-12
NC
◎ Default setting
