Olivetti Explor 200XS - System - Front Panel; System - Rear Panel

XZAC4074 Service Manual 1-3
1.2.1 System – Front panel
Figure 1-6
1.2.2 System – Rear panel
Figure 1-7
ON/OFF BUTTON
USB 2.0
CD-ROM
LPT COM4
VGA
MAINS SUPPLY
KEYBOARD/MOUSE COM1 COM2 COM3
USB 24V POWER
USB 12V POWER
LAN
CASH DRAWER
POWER SUPPLY
UNIT FAN
