XZAC4074 Service Manual 1-19
Model Name EXPLOR@200XS EXPLOR@300XS
Internal interface:
USB USB 5 / 6
COM COM5 for touch screen, COM6 for badge reader
VGA (seconds) 1 x 10 pin
Controls / Indicators
ON/OFF button 1 (frontal)
LED indicator 2 (Power / HDD)
Power supply
Power supply unit 180W ATX – Switching (internal), mains voltage 100-250V AC, tolerance 90-
265V AC, 47-63 Hz.
Environmental characteristics
EMC & Safety
FCC : Class A
EMC : EN55022 / EN61000 –3-2 2000 / EN61000-3-3 / EN55024
LVD : EN60950-1
Operating temperature
5–35°C (41℉ ~ 95℉)
Storage temperature
-20°C - +60°C (-4℉ ~ 140℉)
Humidity 90% RH
Options
Badge reader PS2 o RS-232 (3 tracks)
Second display 10.4” TFT LCD; 12.1” TFT LCD
Customer display VFD / LCD
Other
Dimensions (at 70°) 317 x 355 x 336 mm 378 x 364 x 358 mm
Operating system Windows XP PRO Multilingual
Operating systems
supported
DOS, WIN98, WIN 2000, WIN NT 4.0 sp6, LINUX, WIN XP, WEPOS
