3-4 Operation Items for Test Run
The following describes the operation items for test run.
Check that the inverter meets the installation conditions.
For details on installing the inverter, refer to 2-1 Installation on page 2-5.
Select peripheral equipment according to the specifications and wire the cables securely.
For details on wiring the inverter, refer to 2-3 Wiring on page 2-12.
âš«
Points to be checked before turning ON the power
Check that the power supply voltage is appropriate and that the main power input terminals (R/L1,
S/L2, T/L3) are securely wired.
The rated input voltage of the 3G3MX2-EV2 Series Inverter is as follows.
Check that the motor is securely connected to the inverter output terminals (U/T1, V/T2, W/T3).
Check that the controller is securely connected to the control circuit terminals. In addition, turn off
the control terminals.
Set the motor in a no-load state (not connected to the mechanical system).
âš«
Power-on
If no problem is found in above checks, turn on the power supply.
