4 Parameter List
4 - 5
Multi-function Compact Inverter 3G3MX2-EV2 User’s Manual (I666-E1)
4-2 Function Mode
The table below lists the function mode parameters.
If the data exceeds the display digits, the Digital Operator displays the upper digits for monitoring and
the lower digits for setting. To monitor digits that are not displayed, use the digit shift display mode. For
details, refer to Digit Shift Display Mode on page 3-11.
4-2-1 Group F: Basic Function Parameters
Parameter
No.
Function name
Monitor or data range
Default data
Changes
during
RUN
Unit
Page
F001
Output Frequency
Setting/Monitor
0.0, Starting Frequency to
1st/2nd Maximum Fre-
quency
When the PID function is
enabled: 0.00 to 9999.00
*1
6.00
Enabled
Hz
%
P. 5-23
F002
1st Acceleration
Time 1
0.00 to 3600.00
*1
10.00 (30.00)
*2
Enabled
s
P. 5-32
F202
2nd Acceleration
Time 1
0.00 to 3600.00
*1
10.00 (30.00)
*2
Enabled
s
F003
1st Deceleration
Time 1
0.00 to 3600.00
*1
10.00 (30.00)
*2
Enabled
s
F203
2nd Deceleration
Time 1
0.00 to 3600.00
*1
10.00 (30.00)
*2
Enabled
s
F004
RUN Direction Selec-
tion
00: Forward
01: Reverse
00
Enabled
*3
−
P. 5-21
*1. The digit shift display mode can be used.
*2. In high-frequency mode.
*3. Changing the direction during operation has the same effect as when giving a command in the opposite direc-
tion.
4
4-2 Function Mode
4-2-1 Group F: Basic Function Parameters
