Page #192 background image
4 Parameter List
4 - 32
Multi-function Compact Inverter 3G3MX2-EV2 User’s Manual (I666-E1)
Parameter
No.
Function name
Monitor or data range
Default
data
Set
data
Changes
during
RUN
Unit
Page
Control
parameters
H001
Auto-tuning Selection
00: Disabled
01: Enabled (No motor rotation)
02: Enabled (Motor rotation)
00
Disabled
P. 6-4
H002
1st Motor Parameter
selection
00: Standard motor parameter
02: Auto-tuning data
00
Disabled
P. 6-4
H202
2nd Motor Parameter
Selection
00
Disabled
H003
1st Motor Capacity
0.1/0.2/0.4/0.55/0.75/1.1/1.5/2.2/3.0/3.7/
4.0/5.5/7.5/11.0/15.0/18.5
Maxi-
mum
applica-
ble motor
capacity
Disabled
kW
H203
2nd Motor Capacity
Disabled
kW
H004
1st Motor Pole Num-
ber
2/4/6/8
10 to 48: Do not set.
4
Disabled
pole
H204
2nd Motor Pole Num-
ber Selection
4
Disabled
H005
1st Speed Response
1. to 1000.
100.
Enabled
H205
2nd Speed Response
100.
Enabled
H006
1st Stabilization
Parameter
0. to 255.
100.
Enabled
P. 7-52
H206
2nd Stabilization
Parameter
100.
Enabled
H020
1st Motor Parameter
R1
0.001 to 65.535
Depen-
dent on
capacity
Disabled
P. 6-9
H220
2nd Motor Parameter
R1
Depen-
dent on
capacity
Disabled
H021
1st Motor Parameter
R2
0.001 to 65.535
Depen-
dent on
capacity
Disabled
H221
2nd Motor Parameter
R2
Depen-
dent on
capacity
Disabled
H022
1st Motor Parameter L
0.01 to 655.35
Depen-
dent on
capacity
Disabled
mH
H222
2nd Motor Parameter
L
Depen-
dent on
capacity
Disabled
H023
1st Motor Parameter
Io
0.01 to 655.35
Depen-
dent on
capacity
Disabled
A
H223
2nd Motor Parameter
Io
Depen-
dent on
capacity
Disabled
H024
1st Motor Parameter J
0.001 to 9999.000
*1
Depen-
dent on
capacity
Disabled
kgm
2
H224
2nd Motor Parameter
J
Depen-
dent on
capacity
Disabled
