7 Other Functions
7 - 8
Multi-function Compact Inverter 3G3MX2-EV2 User’s Manual (I666-E1)
7-1-10 Torque Bias Monitor [d010]
Use this function to display the current torque bias value under sensorless vector control.
The torque bias monitor function estimates the torque value equivalent to the rated current of the
inverter as 100%.
To convert it to the rated motor torque ratio, use the following formula:
Rated motor torque ratio = Monitor value  Rated output current of inverter / Rated motor current
For details on the torque bias monitor function, refer to 6-4-2 Torque Bias Function Settings on page
6-17.
Parameter
No.
Function name
Data
Default
data
Unit
d010
Torque Bias Monitor
−200. to 200.
−
%
Related functions
A044, A244, P036, P037, P038
7-1-11 Output Torque Monitor [d012]
Use this function to display the estimated output torque value of the inverter.
The value is displayed only when sensorless vector control is selected.
The output torque monitor function estimates the torque value equivalent to the rated current of the
inverter as 100%.
To convert it to the rated motor torque ratio, use the following formula:
Rated motor torque ratio = Monitor value  Rated output current of inverter / Rated motor current
Parameter
No.
Function name
Data
Default
data
Unit
d012
Output Torque Monitor
−200. to 200.
−
%
Related functions
A044, A244
Note During forward RUN, the value is positive for Power Running and negative for Regeneration. During
reverse RUN, the value is negative for Power Running and positive for Regeneration.
7-1-12 Output Voltage Monitor [d013]
Use this function to display the output voltage of the inverter.
Parameter
No.
Function name
Data
Default
data
Unit
d013
Output Voltage
Monitor
0.0 to 600.0
−
V
Precautions for Correct Use
Set the 1st/2nd Motor Rated Voltage Selection (A082/A282) correctly. Otherwise, the correct
value may not be displayed.
