2-2-3 Preparing Backing Plate
Before wiring the Inverter, cut off the connecting points between the backing plate and unnecessary
portions with nippers or a wire cutter.
Unnecessary
portion
Unnecessary
portion
2
2-2 Removal of Each Part
2-2-3 Preparing Backing Plate
Inverter with 4.0 kW or Higher Capacity
Inverter with 5.5 kW or Higher Capacity
