5-9-2 Multi-function Input Operation Selection
The multi-function input terminals can be set to either NO (NO contact) or NC (NC contact) individually.
This manual describes each function with the Multi-function Input 1 to 7 Operation Selection (C011 to
C017) set to 00 (NO: NO contact). Note that the operations of set signals are reversed when you set
them to 01 (NC: NC contact).
Parameter
No.
Function name
Data
Default
data
Unit
C011
Multi-function Input 1 Operation
Selection
00: NO (NO contact)
01: NC (NC contact)
• Each multi-function input termi-
nal 1 to 7 can be set indepen-
dently to either an NO contact or
NC contact input terminal.
*1
• The terminal allocated to 18 (RS:
Reset) cannot be set to NC
contact. Be sure to set the NO
contact.
00
−
C012
Multi-function Input 2 Operation
Selection
C013
Multi-function Input 3 Operation
Selection
C014
Multi-function Input 4 Operation
Selection
C015
Multi-function Input 5 Operation
Selection
C016
Multi-function Input 6 Operation
Selection
C017
Multi-function Input 7 Operation
Selection
Related functions
C001 to C007
*1. NO contact: ON when closed, OFF when open
NC contact: ON when open, OFF when closed
5-9-3 Input Terminal Response Time
• Set the response time for each multi-function input 1 to 7 terminal independently.
This function is effective for removing noise caused by chattering etc.
• If the terminal input becomes unstable because of chattering, increase the set value.
However, increasing the set value results in a slow response.
The setting range is 0 to 200, which provides a response time of approximately 2 to 400 ms.
Parameter
No.
Function name
Data
Default
data
Unit
C160 to
C166
Multi-function Input 1 to 7
Response Time
0. to 200. ( 2 ms)
*1
1.
ms
*1. When 0 is set, the response time is 2 ms.
5-9-4 Forward RUN Command (FW) and Reverse RUN Command (RV)
• To input the forward and reverse RUN commands via the control circuit terminals, set the Multi-func-
tion Input 1 to 7 Selection (C001 to C007) to 00 (FW) and 01 (RV).
• By default, the Multi-function Input 1 Selection (C001) is set to 00 (FW) and the Multi-function Input 2
Selection (C002) is set to 01 (RV), respectively.
• To input the RUN command via these control circuit terminals, set the 1st/2nd RUN Command Selec-
tion (A002/A202) to 01 (Control circuit terminal block).
• If the terminals FW and RV turn ON simultaneously, the inverter will stop without displaying any
alarm. It will start operating again when either of these terminals turns OFF.
Parameter
No.
Function name
Data
Default
data
Unit
C001 to
C007
Multi-function Input 1 to 7 Selection
00: FW (Forward)
01: RV (Reverse)
−
−
5
5-9 Multi-function Input Settings
5-9-2 Multi-function Input Operation Selection
