8-9-5 2nd Control Register Number List
Precautions for Correct Use
• The “Register No.” in the table header shows the register number used inside the inverter.
Use this register number when setting EtherCAT communications.
• The “Modbus register spec. No.” in the table header shows the register number used to actu-
ally specify the register in the Modbus communication process.
This register number is 1 less than the inverter “Register No.” according to the Modbus com-
munication specifications.
⚫ Group F
Register
No.
Modbus
register
spec. No
Function name
Parameter
No.
R/W
Monitor or setting data
Data
resolution
Page
2103 hex
2102 hex
2nd Acceleration
Time 1
F202
(HIGH)
R/W
0 to 360000
0.01 [s]
P. 5-32
2104 hex
2103 hex
F202
(LOW)
R/W
2105 hex
2104 hex
2nd Deceleration
Time 1
F203
(HIGH)
R/W
0 to 360000
0.01 [s]
2106 hex
2105 hex
F203
(LOW)
R/W
2107 to
2200 hex
−
Not used
−
−
Not accessible
−
−
⚫ Group A/b/C/H/P
Register
No.
Modbus
register
spec. No
Function name
Parameter
No.
R/W
Monitor or setting data
Data
resolution
Page
2201 hex
2200 hex
2nd Frequency Ref-
erence Selection
A201
R/W
00: Volume
01: Control circuit ter-
minal block (Ana-
log input)
02: Digital Operator
03: Modbus communi-
cation
04: Option
06: Pulse train fre-
quency
07: DriveProgramming
10: Operation function
output
−
P. 5-23
2202 hex
2201 hex
2nd RUN Command
Selection
*1
A202
R/W
01: Control circuit ter-
minal block (Drive-
Programming)
02: Digital Operator
03: Modbus communi-
cation
04: Option
−
P. 5-21
*1. If you change the 2nd RUN Command Selection setting, be sure to wait at least 40 ms before actually inputting
the RUN command.
