5 Basic Settings
5 - 46
Multi-function Compact Inverter 3G3MX2-EV2 User’s Manual (I666-E1)
5-9 Multi-function Input Settings
5-9-1 Multi-function Input Selection
• You can allocate the functions shown in the following table to the multi-function input terminals 1 to 7
to use them.
• This section describes seven types of primary functions. For other functions, refer to 7-2
Multi-function Input/Output Functions on page 7-18.
To allocate the functions, set the values shown in the Data column of the following table in the
Multi-function Input 1 to 7 Selection (C001 to C007).
• Do not allocate the same function to more than one multi-function input terminal. If you allocate the
same function to more than one multi-function input terminal by mistake, the function will be set only
for the terminal to which you allocated last and the previously allocated terminal will be reset to 255
(no: No allocation).
Parameter
No.
Data
Function name
Reference item
Page
00
FW: Forward
Forward run command
P. 5-47
01
RV: Reverse
Reverse run command
P. 5-47
02
CF1: Multi-step speed setting binary 1
P. 5-48
03
CF2: Multi-step speed setting binary 2
Multi-step speed operation
04
CF3: Multi-step speed setting binary 3
function
05
CF4: Multi-step speed setting binary 4
06
JG: Jogging
Jogging
P. 5-51
Multi-function
09
2CH: 2-step acceleration/deceleration
2-step acceleration/deceleration
P. 5-52
18
RS: Reset
Reset
P. 5-52
Input 1 to 7
20
STA: 3-wire start
Selection
(C001 toC007)
3-wire input function
P. 5-53
21
STP: 3-wire stop
22
F/R: 3-wire forward/reverse
32
SF1: Multi-step speed setting bit 1
Multi-step speed operation
function
33
SF2: Multi-step speed setting bit 2
34
SF3: Multi-step speed setting bit 3
35
SF4: Multi-step speed setting bit 4
P. 5-48
36
SF5: Multi-step speed setting bit 5
37
SF6: Multi-step speed setting bit 6
38
SF7: Multi-step speed setting bit 7
